Stäubli is entering a new performance class with its TS2 SCARA series. The completely redesigned 4-axis machine with proprietary JCS drive technology facilitates ultra-short cycle times and high repeatability. It also has a revolutionary encapsulated design which opens up new possibilities for use in sensitive environments. It is piloted by the generic CS9 controller that also controls TX2 6-axis robots.
The fast and compact TS2-40 robot has special features, such as a maximum payload of 8.4 kg with a 460 mm reach.
| Model | TS2-40 |
|---|---|
| Degrees of freedom | 4 |
| Load capacity | 8.4 kg |
| Reach | 460 mm |
| Stroke | 200 mm or 400 mm (option) |
| Repeatability X-Y | ± 0,01 mm |
| Repeatability Z | ± 0,004 mm |
| Repeatability R-Z | ± 0,002° |
| Protection class - EN 60529 | Up to IP65 with ball screw cover and bellows |
| Attachment methods | Floor or ceiling |
| Stäubli controller | CS9 |
