Ideal for weaving carpet, velvet and technical fabrics on all types of weaving machines, Stäubli electronic Jacquard machine LX 2494 opens up new avenues in heavy fabric weaving with its impressive and elegant lifting mechanism. The Stäubli M6T 3-position module principle makes the machine particularly compact, and plays an important role in exploiting its performance potential.
The Jacquard machine LX 2494 is very robust, wear-resistant, and designed for many years of daily use with a minimum of maintenance.
CHARACTERISTICS / MODEL | LX 2494 |
|---|---|
Field of application | Carpet, velour, technical textile weaving machines |
Fabric suitability | All types of heavy fabrics |
Available formats | 6,720 hooks (280 rows of 24 modules) 8,448 hooks (352 rows of 24 modules)* |
Drive system and shedding |
|
Hook selection | Stäubli M6T module with QUICK LINK connection |
Electronic control | Independent Stäubli JC7T control unit, synchronized with the weaving machine |
* Formats up to 33,792 can be achieved by combining 4 machines
