TX2touch is the only cobot with the SIL3/PLe safety level. It is highly productive due to the performance, smart connectivity and reliability inherited from TX2 robots and its CS9 controller.
The TX2touch-90 series has a payload of up to 10 kg with a maximum reach of 1450 mm.
Up to 1450 mm
Up to 10 kg
Thanks to the combined use of a set of 5 unique modular SIL3-PLe safety functionalities, the TX2touch cobot range is the safest on the market while maintaining a high level of productivity.
The cobot reacts in 10 ms whenever it comes into contact with an operator. Contact is harmless, since the cobot’s skin is up to 20 mm thick to optimize the safety of all Man–Robot interactions.
The robot switches to a reduced speed (≤ 250 mm/s) as soon as the operator enters the environment, regaining full speed once the operator is gone.
The robot slows down as the operator approaches, stops during the interaction, and starts up again at the end of the interaction.
Safe zones ensure safe limited arm performance within predefined areas.
SafeTool is supervising robot’s tools or grippers dimension and speed.
