CombiTac world - plug into more possibilities

CombiTac modular connector systems

The modular connector CombiTac

Stäubli's CombiTac modular connectors offer optimal long-lasting connections. This innovative connection solution is optimized for highest-performance up to 100,000 mating cycles, making it an ideal choice for customers seeking durable and adaptable solutions. CombiTac is engineered to offer the highest customization through an intuitive online configurator, ensuring precise tailoring to meet the most demanding requirements.

MULTILAM contact technology for safe and durable connections
Up to 100,000 mating cycles
Space-saving solution
Available in housing or panel mounting
Signal, power, high-voltage, data and fiber connections
Pneumatic and fluid couplings

Configure your own CombiTac

QUICK ACCESS

Overview-flyer
CombiTac direqt catalog
CombiTac uniq catalog
CombiTac documentation and downloads
CombiTac assembly instructions
MyCombiTac (old name MyLogin)
(for registered users)

Each application has its own unique requirements, so we offer two different CombiTac lines to meet those specific needs.

	CombiTac direqt	CombiTac uniq
Download	Catalog	Catalog
Sizes Panel mount	4 standard frame sizes	18 mm to 180 mm (in 2 mm steps) Additional lengths available upon request
Housing sizes	6	6
Aluminum housing IP65, IP67, IP68/69K	✓	✓
Plastic housings IP65	✓	✓
Light housing		✓
Housing PE module		✓
Power	Up to 350 A	Up to 400 A
High Voltage (up to 5 kV)		✓
Signal	✓	✓
Last mate first break (monitoring)	✓	✓
Data	✓	✓
Ethernet	up to 1 Gbit	up to 10 Gbit
Coaxial	✓	✓
Fiberoptic		✓
Thermocoupling		✓
Pneumatic	✓	✓
Fluid		✓
Mating cycles	10,000	100,000
Temperature range (ºC)	-40 to +125	-40 to +90
Carrier material	PA	PA, EPTR, PEEK
Railway fire & smoke compliance	✓	✓
Vibrations & shock resistance	✓	✓
Contact termination type	Crimp, PCB	Crimp, PCB, screw
Delivery	Assembled (contacts separate)	Assembled (contacts separate)
Requires contact insertion tools		Stäubli tools(*)
Carrier removal tools	Standard flat screwdriver
Contact removal tools	Standard flat screwdriver	Stäubli tools(*)
Cable assembly	✓	✓
Customization		✓

(*) Depending on contact type

CombiTac direqt

The CombiTac direqt modular connector is the perfect simple connector for highest efficiency. It offers a variety of contacts for power, signal, data and pneumatic couplings. Up to 10,000 mating cycles, CombiTac direqt provides high performance and is quick to assemble with its easy-to-use, tool-free click-and-connect system.

Discover now

CombiTac uniq

The CombiTac uniq modular connector is ideal for the most demanding applications. It offers a variety of contacts for power, high-voltage, signal, data, fiber optics and pneumatic and fluid couplings. With up to 100,000 mating cycles, CombiTac uniq provides high performance and can be customized to meet exact technical and dimensional specifications.

Discover now

Discover our modular connectors CombiTac uniq and direqt

Easy-to-use configurator

The CombiTac configurator enables you to create a customized CombiTac for your requirements. The interactive 3D graphics guide you through the process. After successfully completing the configuration, free STEP files are available for you to download.

PV installations are expected to last reliably for more than 25 years. Therefore, when wiring the PV system, correct and safe assembly and crimping with qualified tools is key. Follow the step-by-step guidance through assembly and crimping for Stäubli solar connectors. By using the qualified tools by Stäubli for PV connector installation you enhance the quality of the PV DC connection.

Configure CombiTac now

CombiTac applications

CombiTac modular connectors are ideal for a variety of demanding applications such as testing, healthcare, construction machines, logistics and drones.

Discover the various applications

Cable assembly – plug and play

Up on request, Stäubli offers cable harnessing for CombiTac straight from the factory. This helps to save installation time and reduces assembly costs.

More about cable assembly

Success Stories

WFT - pre-assembled connection solution for AGVs

The WFT's AGVs feature full 360-degree navigation. Stäubli’s CombiTac system with pre-assembled cables for flexible and precise movement, ensuring reliable performance for the specific requirements of these AGVs.

AKASOL – robust connector for high-performance battery systems

AKASOL is a technology leader in high-performance, modular battery systems for electric/hybrid commercial vehicles. Their reliable, scalable batteries with durable CombiTac connectors and customized cables ensure safe, extended use of electric vehicles.

KOSF- smart factory modular cubes with connective system

The Korea Smart Factory Association's (KOSF) Smart Cubes are modular blocks that simulate and pattern the entire manufacturing process for analysis. The cubes can be connected with our CombiTac connector system.

Could not find what you are looking for?

We’re happy to help!

CombiTac is a great solution that can be used for almost every application. Should you have different requirements or could not find what you were looking for, please do not hesitate to reach out to our specialists.
